Network Power solution provider!
5 Years
| Ask Lasest Price | |
| Brand Name : | HAIRF |
| Model Number : | P5000U |
| Certification : | CE 3CE RoHS |
| Price : | $4038-$10500/set |
| Payment Terms : | T/T |
| Supply Ability : | 1000set/month |
| Delivery Time : | 35-45days |
| Model:HADC/HAUC | 0061 | 0081 | 0101 | 0111 | 0131 | 0161 | 0191 | 0201 | |
| Cooling capacity(1) | kw | 5.9 | 7.7 | 9.3 | 10.6 | 12.6 | 15.6 | 18.2 | 20.5 |
| Air flow | m³/h | 1720 | 2150 | 2850 | 3200 | 3530 | 4800 | 5200 | 5700 |
| EER | 3.6 | 3.65 | 3.55 | 3.65 | 3.6 | 3.65. | 3.65 | 3.66 | |
| SHR | 0.95 | 0.93 | 0.95 | 0. 95 | 0.93 | 0.96 | 0.93 | 0.93 | |
| | Compressor | |||||||||
| Type | |||||||||
| Capacity | kw | 1.5 | 1.9 | 2.2 | 2.3 | 3 | 3.6 | 4.3 | 5.3 |
| Quantity | nr | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Finned coll evaporator | |||||||||
| Frontal suface | ㎡ | 0.29 | 0.29 | 0.47 | 0.47 | 0.47 | 0.65 | 0.65 | 0.65 |
| Geometry | mm | ||||||||
| Type of fins | |||||||||
| FIn pitch | mm | ||||||||
| Fan section | |||||||||
| Type | |||||||||
| Quantity | nr | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 2 |
| Absorbed current | A | 1.2 | 1.6 | 3.2 | 3.2 | 3.2 | 3.8 | 3.8 | 3.8 |
| Absorbed power | W | 165 | 282 | 500 | 563 | 563 | 668 | 668 | 850 |
| AESP Max Speed(2) | Pe | 180 | 180 | 180 | 250 | 250 | 250 | 250 | 250 |
| Air flter | |||||||||
| Eficiency | |||||||||
| Overall surface | ㎡ | 2.2 | 2.2 | 3.6 | 3.6 | 3.6 | 5 | 5 | 5 |
| Fire reslstance dlass | |||||||||
| I Electrical heaters | |||||||||
| Total heating capaclty | kw | 2 | 2 | 2.5 | 2.5 | 2.5 | 5 | 5 | 5 |
| Quantity | nr | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 |
| Material | |||||||||
| Humidifier | |||||||||
| Capacty | Kg/h | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 |
| Absorbed power | kw | 2.25 | 2.25 | 2.25 | 2.25 | 2.25 | 2.25 | 2.25 | 2.25 |
| Dimension&Weight | |||||||||
| Height | mm | 1875 | 1875 | 1875 | 1875 | 1875 | 1875 | 1875 | 1875 |
| Length | mm | 600 | 600 | 900 | 900 | 900 | 1200 | 1200 | 1200 |
| Depth | mm | 449 | 449 | 49 | 449 | 449 | 449 | 449 | 449 |
| Welght | kg | 150 | 157 | 195 | 210 | 230 | 245 | 255 | 270 |
| Sound level | |||||||||
| Sound pressure lel(3) | db(A) | 46 | 48 | 48 | 49 | 51 | 52 | 53 | 52 |
1 High quality control component
It strictly complies with CE and IEC standards and is empowered
with advanced electric control technology and able to work under a
power source of 380V±20%. In addition, it is installed with a power
supply protection module, enabling it to make a selection of
protective value in a range of 380V±50%. When voltage goes beyond
the selected range, it will automatically protect the unit. While
the voltage becomes normal, it will automatically restart the unit.
2 Evaporator
An efficient evaporator made from quality material with advanced
professional technology and featuring large heat exchange area and
the realization of higher sensible heat factor of precision air
conditioning unit.
3 Expansion Valve
Expansion valve adopts advanced thermal expansion valves with
strong reliability and stability and can precisely control the
supply of refrigerant. In order to achieve the reduction of energy
consumption for refrigeration equipment, we employ advanced
electronic expansion valves in high-performance precision air
conditioning units to realize less energy
consumption.
4 Humidifier
An internationally advanced electrode steam humidification system
under which the amount of humidification and water inflow and
outflow are all
controlled by computer, the auto cleaning program for the
humidifier cylinder ensure normal humidification effciency of the
clinder.
5 Filter
Air filter which is EU4 standard which is metallic bracket ,
filtering the dust and particulate effectively by air circulation ,
then purifying the air environment of telecom room.
6 Cabinet
With unique frame design and black steel framewor demonstrating
consummate production technology, professional design and elegant
appearance, the cabinet guarantees the safety of the unit under any
transport condition and operating environment.
7 Scroll Compressor
The core power of the unit is from Copeland hermetic scroll
compressor that guarantees the high efficiency ,low noise and the
long life of the unit.
8 Indoor blower fan
A blow fan adopts direct drive centrifugal fan with backward curved
blades, the range of static pressure can be adjusted from 0 to
400pa, realizing the continuous operation of 365 days* 24 hours, 10
years’ average life.
The high-performance unit employ energy-saving EC fan controlled by
0-10V signal,DC driven and stepless speed regulation,which is more
excellent than traditional fan in energy-saving filed.
9 Heater
An electric heater with perfect overheat protection function and
ionization resistance, able to meet environmental requirements of
the small heat-load machine rooms for base stations in cold
arctic-alpine area.
10 Condenser
With an enclosure of anti-corrosion alloy that ensures service life
and appearance of the is elaborately designed and able to satisfy
the environmental protection requirements on noise, and a fan speed
regulator that controls the rotating speed under different
temperature and ensures sound operating effect and energy saving.
FAQ
Q:What are your factory main products?
A:Precision Air Conditioners,UPS & Data center.
Q:How to choose Precision air conditioner and UPS brand?
A:Hairf brand have reliable quality and reasonable price.
Q:What is your company strength?
A:A strong team with more than 20 years of experiences of
manufacturing air conditioners and
UPS,we have our own Lab,R&D Center,Assembly Line, QC Staff &
Equipments.
Q:What about the Warranty Service?
A:AII products have 1 year guarantee under no artificlal damage.
|
|
