| Brand Name : | HAIRF |
| Model Number : | R161A |
| Certification : | CE 3C RoHS ISO |
| Price : | $2699-8519/set |
| Payment Terms : | T/T |
| Supply Ability : | 500set/month |
| Delivery Time : | 35-45days |
| Modelandoor unit) | R161A | R261A | R361A | |
| Main Power Supply | 380V 3Ph-50Hz | |||
| 40℃DB / 20%RH | ||||
| Total cooling Capacity (kW) | 15.5 | 25.5 | 41.6 | |
| Sensible cooling capacity(kW) | 15.5 | 25.5 | 41 .6 | |
| 37℃DB / 24%RH | ||||
| Total cooling Capacity (kW) | 14.7 | 24.1 | 39.9 | |
| Sensible cooling capacity(kW) | 14.7 | 24.1 | 39.9 | |
| 35℃DB / 26%RH | ||||
| Total cooling Capacity (kW) | 14.1 | 22.9 | 37.9 | |
| Sensible cooling capacity(kW) | 14.1 | 22.9 | 37.9 | |
| 32℃DB / 29%RH | ||||
| Total cooling Capacity (kW) | 13.2 | 21.6 | 36.8 | |
| Sensible cooling capacity(kW) | 13.2 | 21.6 | 36.1 | |
| 30℃DB / 34%RH | ||||
| Total cooling Capacity (kW) | 12.5 | 20.5 | 35.3 | |
| Sensible cooling capacity(kW) | 12.5 | 20.5 | 33.6 | |
| Displacement(m/ h) | 2800 | 5200 | 8600 | |
| Fan quantity | 6 | 6 | 3 | |
| Electric heater | ||||
| Heating capacity kW | 3 | 3 | 6 | |
| Humidifier | ||||
| humidify capacity-kg/h | 3 | 3 | 3 | |
| Pipe dimensions | ||||
| Liquid pipes mm | 12.7 | 12.7 | 15.9 | |
| sas pipes -mm | 19.05 | 19.05 | 22.2 | |
| Hunidifier inlet pipes(mother srew) | G3/4" | G3/4" | G3/4" | |
| Condensing pump dain pipes imer diameter | 25 | 25 | 25 | |
| Width*Depth*Height (mm) | 300 × 1080×2000 | 300 × 1080×2000 | 600 × 1080×2000 | |
| Weight(kg) | 115 | 155 | 340 | |
| Max.working current of condensing unit(A) | ||||
| Single cooling | 12.2 | 19.1 | 31.8 | |
| Single cooling+ Humidifer | 15.7 | 21.8 | 35.9 | |
| | Single coling+ Humidifier theaing | 16.9 | 23.5 | 41.3 | |
| Recommended air switch and cables sizes | ||||
| Single cooling | Air switch (A) | 32 | 32 | 50 |
| Cables ( mm2) | 6 | 6 | 10 | |
| Single cooling+Humidifier | Air switch (A) | 32 | 32 | 50 |
| Cables ( mm2) | 6 | 6 | 10 | |
| Single cooling+Humidifer+heating | Air switch (A) | 32 | 32 | 63 |
| Cables ( mm2) | 6 | 6 | 10 | |
| Modelandoor unit) | R161W | R261W | R361W | |
| Main Power Supply | 380V 3Ph-50Hz | |||
| 40℃DB / 20%RH | ||||
| Total cooling Capacity (kW) | 16.7 | 27.5 | 42.3 | |
| Sensible cooling capacity(kW) | 16.7 | 27.5 | 42.3 | |
| 37℃DB / 24%RH | ||||
| Total cooling Capacity (kW) | 15.6 | 25.9 | 41.2 | |
| Sensible cooling capacity(kW) | 15.6 | 25.9 | 41.2 | |
| 35℃DB / 26%RH | ||||
| Total cooling Capacity (kW) | 15.3 | 23.8 | 38.8 | |
| Sensible cooling capacity(kW) | 15.3 | 23.8 | 38.8 | |
| 32℃DB / 29%RH | ||||
| Total cooling Capacity (kW) | 14.3 | 22.6 | 37.4 | |
| Sensible cooling capacity(kW) | 14.3 | 22.6 | 36.8 | |
| 30℃DB / 34%RH | ||||
| Total cooling Capacity (kW) | 13.5 | 21.9 | 36.7 | |
| Sensible cooling capacity(kW) | 13.5 | 21.9 | 34.7 | |
| Displacement(m/ h) | 3000 | 5500 | 8200 | |
| Fan quantity | 6 | 6 | 3 | |
| Electric heater | ||||
| Heating capacity kW | 3 | 3 | 6 | |
| Humidifier | ||||
| humidify capacity-kg/h | 3 | 3 | 3 | |
| Pipe dimensions | ||||
| Liquid pipes mm | 12.7 | 12.7 | 12.7 | |
| sas pipes -mm | 19.05 | 19.05 | 19.05 | |
| Hunidifier inlet pipes(mother srew) | G3/4" | G3/4" | G3/4" | |
| Condensing pump dain pipes imer diameter | 25 | 25 | 25 | |
| Width*Depth*Height (mm) | 300 x 1080x 2000 | 300 x 1080x 2000 | 300 x 1080x 2000 | |
| Weight(kg) | 120 | 150 | 150 | |
| Max.working current of condensing unit(A) | ||||
| Single cooling | 11.8 | 19 | 31.1 | |
| Single cooling+ Humidifer | 15.5 | 21.5 | 34.6 | |
| | Single coling+ Humidifier theaing | 16.7 | 23.4 | 40.5 | |
| Recommended air switch and cables sizes | ||||
| Single cooling | 32 | 32 | 50 | |
| Single cooling+Humidifier | 6 | 6 | 10 | |
| 32 | 32 | 50 | ||
| Single cooling+ Humidifier+heating | 6 | 6 | 10 | |
| 32 | 32 | 63 | ||
| Single cooling+ Humidifier+heating | 6 | 6 | 10 | |
|
|
